| Size of Hammer | Kgs. | 500 | 750 | 1000 | 1500 | 2000 |
| Weight of Tup | Kgs. | 550 | 800 | 1200 | 1800 | 2200 |
| Space between Slides | mm. ln. |
508 20 |
560 22 |
635 25 |
711 28 |
800 31½ |
| Maximum Stroke | mm. Ft.ln. |
1525 5'0" |
1675 5'6" |
1675 5'6" |
1830 6'0" |
1830 6'0" |
| Tup (Front to Back) | mm. ln. |
370 14½ |
410 16 |
455 18 |
533 21 |
597 23½ |
| Total Height of Machine | mm. Ft.ln. |
5260 17-3 |
5740 18-10 |
6000 19-8 |
6450 21-2 |
6790 22-3 |
| Max. Wt.of the top die | Kgs. Lbs. |
150 330 |
225 500 |
300 660 |
450 992 |
600 1322 |
